Description: APC Easy UPS On-Line SRV3KI, 3kVA/2400W, Tower, 230V, 6x IEC C13 + 1x IEC C19 outlets, Intelligent Card Slot, LCD

APC Easy UPS On-Line SRV 3000VA 230V SRV3KI

APC UPS SRV-KI eg-tech.

Replacement battery is available.
3kVA/2400W double-conversion on-line pure sine wave tower UPS.
High operating efficiency in energy-saving ECO mode.
Prolonged battery life with intelligent temperature-compensated charging.
Easy-to-read LCD interface for detailed and accurate information on UPS status.
Environmental performance of the product.

SRV3KI

Overview
Presentation	High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions.
Lead time	Usually in Stock
Main
rated power in W	2400W
rated power in VA	3000VA
nb of power socket outlets	6 IEC 60320 C13
nb of power socket outlets	1 IEC 60320 C19
output voltage	230 V
Output voltage	220 V
Output voltage	240 V
input voltage	230 V
plug standard	IEC 60320 C20
cable length	1.5m
number of cables	1
General
Number of power module filled slots	0
Number of power module free slots	0
redundant	No
provided equipment	Basic UPS signalling RS-232 cable
	CD with software
	User manual
	USB cable
Physical
mounting mode	Not rack-mountable
depth	42.5cm
height	33.6cm
product weight	26.8kg
width	19cm
USB compatible	Yes
color	Black
Input
Input voltage	220 V
Input voltage	240 V
input voltage limits	110...285 V half load
input voltage limits	160...280 V full load
network frequency	40...70 Hz
Output
bypass type	Internal bypass (automatic and manual)
crest factor	3:01
Maximum configurable power in VA	3000VA
Maximum configurable power in W	2400W
UPS type	Double conversion online
Wave type	Sine wave
runtime at 600W	0:31:00
half load runtime	00:13:00 1200 W
efficiency	88% (full load)
output frequency	50/60 Hz +/- 3 Hz sync to mains
Conformance
product certifications	CE
product certifications	EAC
standards	EN/IEC 62040-1
standards	EN/IEC 62040-2
Environmental
acoustic level	50 dBA
operating altitude	0...3000 m
ambient air temperature for operation	0 40C
ambient air temperature for storage	-20 50C
storage altitude	0 15000m
IP degree of protection	IP20
relative humidity	0 95% non-condensing
storage Relative Humidity	Non-condensing 0 95%
Batteries & Runtime
additional information	Configurable for 220 : 230 or 240 nominal output voltage
battery type	Lead-acid battery
battery voltage	72 V
number of battery filled slots	0
number of battery free slots	0
Battery recharge time	4h
battery life	3year(s)
Battery power in VAH	473 VAh runtime
battery charger power	118W rated
Communications & Management
alarm	Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
control panel	Multifunction LCD status and control console
free slots	1
Surge Protection and Filtering
Surge energy rate	600J
Packing Units
Package 1 Weight	29kg
Package 1 Height	46.5cm
Package 1 width	32.5cm
Package 1 Length	56.5cm
