Synology SA3400D 12-Bay Active-Passive NAS Enclosure with Dual Controllers (Diskless)

Synology SA3400D NAS Storage
Keep services online with efficient high-availability storage

Original price was: 900.051,00 EGP.Current price is: 766.740,00 EGP. 14% inc VAT

Sold by EG-tech

📱 Contact via WhatsApp

📞
Your number saved
Buy Now
Availability: Available on backorder
SKU:SA3400D

Synology SA3400D is Designed for reliable data storage, the dual controller Synology SA3400D provides a cost-effective and compact high-availability solution for businesses of all sizes. With up to 192 TB of raw storage capacity (576 TB when fully expanded), this 12-bay enterprise server is equally suitable for file and block storage. Advanced data management and backup solutions for physical endpoints, VMs, and SaaS applications are all available in the Synology DiskStation Manager (DSM) operating system.

    • Accessible and convenient
      Maintain data availability with an active-passive high availability dual-controller module
    • Versatile applications
      Manage, distribute, and protect data, back up endpoints, and guard physical premises
    • Fast and efficient
      Over 3,500/2,900 MB/s seq. read/write throughput and over 500 TB maximum storage capacity

Built-in High Availability
Keep file sharing services, block storage, backups, and other office applications online with automatic minute-level failover. Defend against operational disruptions with two independent and hot-swappable controllers operating in an active-passive configuration.

Made for demanding environments
The SA3400D is engineered to provide outstanding performance in both NAS and SAN storage roles. Its throughput and random I/O performance support efficient SMB and NFS file serving as well as a range of iSCSI and Fibre Channel block storage applications.

Consolidate your data infrastructure
Manage, protect, and share data with versatile business solutions. Empower team collaboration, sandbox applications, and provide VM storage on a unified platform.

Synology SA3400D NAS Storage ports eg-tech

  1. Power Button and Indicator
  2. High Availability Status Indicator
  3. Alert Indicator
  4. Mute Button
  5. Drive Status Indicators
  6. Drive Trays
  7. Rail Kit Release Tabs
  8. Power Ports
  9. PSU Indicators
  10. PSU Fans
  11. PCI Express Expansion Slots
  12. Console Ports
  13. 1GbE RJ-45 Ports
  14. 10GbE RJ-45 Ports
  15. Expansion Ports
  16. Reset Buttons
  17. Remove Indicators
  18. Alert Indicators
  19. Status Indicators
  20. Power Indicators
Condition

New

Model

SA3400D NAS Storage

CPU

Intel Xeon D-1541

Internal Memory

8 GB DDR4

Drive Bays

12

Form Factor

Rackmount 2U

FAN (Number)

2

Dimensions

8.8 x 43 x 69.2 cm

Weight

19.7 kg

Hardware Specifications
Controller Number of Controller Module 2
CPU CPU Model Intel Xeon D-1541
CPU Quantity 1 (per controller)
CPU Core 8
CPU Architecture 64-bit
CPU Frequency 2.1 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine Yes
Memory System Memory 8 GB DDR4 ECC UDIMM (per controller)
Memory Module Pre-installed 8 GB (8 GB x 1) (per controller)
Total Memory Slots 4 (per controller)
Maximum Memory Capacity 64 GB (16 GB x 4) (per controller)
Storage Drive Bays 12
Maximum Drive Bays with Expansion Unit 36 (RXD1219sas x 2)
Drive Type (See all supported drives) 3.5” dual-port SAS HDD
2.5” dual-port SAS SSD
Hot Swappable Drive* Yes
External Ports RJ-45 1GbE LAN Port 2 (per controller)
RJ-45 10GbE LAN Port 1 (per controller)
Expansion Port 1 (per controller)
Expansion Port Type Mini-SAS HD
PCIe PCIe Expansion 1 x Gen3 x8 slot (x8 link) (per controller)
Appearance Form Factor (RU) 2U
Size (Height x Width x Depth) 88 mm x 482 mm x 724 mm
Weight 19.7 kg
Rack Installation Support* 4-post 19" rack (Synology Rail Kit - RKS-02)
Notes The rail kit is sold separately
Others System Fan 60 mm x 60 mm x 2 pcs
Fan Speed Mode Full-Speed Mode
Cool Mode
Quiet Mode
Easy Replacement System Fan Yes
Power Recovery Yes
Noise Level* 51.3 dB(A)
Power Supply Unit / Adapter 500 watts
Redundant Power Supply Yes
AC Input Power Voltage 100V to 240V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 257.78 watts (Access)
British Thermal Unit 879.58 BTU/hr (Access)
Warranty 5 Years
Environment RoHS Compliant
Packaging Content Main Unit X 1
Accessory Pack X 1
AC Power Cord X 2
Quick Installation Guide X 1
